MK03-1A66B-500W
Reed Switch, MK03 Series, Cylindrical, SPST-NO, 10 W, 200 Vac/dc, 0.5 A, 10 to 15 AT
Precisa de mais?
| Quantidade | |
|---|---|
| 1+ | 7,890 € |
| 10+ | 4,780 € |
| 25+ | 4,380 € |
| 50+ | 4,040 € |
| 100+ | 3,510 € |
Informação do produto
Descrição geral do produto
The MK03-1A66B-500W is a 15mm cylindrical Reed Sensor with 1 form-A contact. The sensor is magnetically operated reed proximity switches in a cylindrical case with an interconnect cable. The cable-cut length with 5mm of wire stripped and tinned termination. The sensor should be mounted on a fixed surface with the actuating magnet on the moving surface. Introduction or removal of the magnetic field determines the closing and opening of the reed switch. Suitable for position and limit switch, pneumatic or hydraulic actuator position Indication and end travel limit switch. Door and window contacts, security system applications. Level sensors use with magnetic floats for water level detection in coffee makers, washing machines or dishwashers.
- High power switches
- 66 Switch model
- 10 to 15 Pull-in AT magnetic sensitivity
- 500mm Cable length
Aplicações
Industrial, Sensing & Instrumentation, Security, Consumer Electronics
Especificações Técnicas
15mm
15mm
250mA
85°C
Cylindrical Reed Sensor
-
-20°C
MK03 Series
Documentação técnica (1)
Legislação e Ambiente
País onde se realizou a maior parte do processo de produçãoPaís de origem:China
País onde se realizou a maior parte do processo de produção
RoHS
RoHS
Certificado de conformidade de produto
